2004 Sea Ray 260 Sundancer

Description

The 260 Sundancer has the sleek good looks and high-caliber performance you?d expect from a much larger, much more expensive cruiser. No other boat in its class can offer the luxurious appointments found in the 260 Sundancer. It?s packed with creature comforts inside and out. Smoothly powered by a MerCruiser® 260 hp 5.0L MPI Bravo® III stern drive, the 260 Sundancer is truly a boat that lets you and your guests get the utmost enjoyment out of the weekend.

Propulsion Options

• (240 hp - 179 kW) Volvo KAD 44P EDC/DP Diesel Stern Drives (240 hp - 179 kW) ; (SmartCraft™ Systems N/A on Diesel Engine Applications)
• (275 hp - 202 kW) Volvo KAD 300 EDC/DP Diesel Stern Drive (275hp - 202 kW) ; (SmartCraft™ Systems N/A on Diesel Engine Applications)
• (300 hp - 224 kW) 350 Magnum® MPI Bravo® III MCM Gasoline Stern Drives (300 hp - 224 kW)
• (320 hp - 239 kW) MX6.2L MPI Bravo® III MCM* Gasoline Stern Drives (320 hp - 239 kW) ; *Fuel-Injected Engines Std. w/Stainless Steel Propeller & Remote Oil Filler

Propulsion

• (260 hp - 194 kW) 5.0L MPI Bravo® III MCM Stern Drive (260 hp - 194 kW)

Key Features

• Cherry wood Formica® cabinets.
• Dedicated storage for V-berth cushions and tables.
• Large extended swim platform with concealed stainless steel swim ladder.
• Optional fiberglass sport spoiler.
• Portside seating which easily converts to sun pad.
• Transom locker provides abundant storage for gear.
• V-berth gunwale storage cabinets.

Specifications Without Trailer

• Beam: 8' 6" / 2.59 m
• Dead Rise: 19º / 19º
• Draft - Stern Drive Down: 35" / 88.9 cm
• Draft - Stern Drive Up: 22" / 55.9 cm
• Dry Weight: 6,200 lbs / 2,812 kg
• Fuel Capacity: 84 gal / 317.9 L
• Holding Tank: 28 gal / 106 L
• Overall Length: 28'0"/8.53 m
• Water Capacity: 28 gal / 106 L

Optional Packages

• Camper Canvas Package Camper Aft Curtain (Std. Aft Curtain is Deleted) ; Camper Top w/Boot & Vertical Storage ; Front Curtains ; Side Curtains (Bimini & Camper)

Individual Options

• Anchor Chute w/Hawse Pipe
• Bottom Paint (Std. on V-Drives)
• Canadian Conformity Plate
• Canvas, Black (in lieu of Std. Colors)
• Canvas, Cockpit Cover
• Carpet Liner, Snap-In (Cockpit)
• Carpet Runners Sunbrella®
• CD Changer, 6-Disc
• CE Option Group
• Colored Hull (Blue or Green Only) w/Stainless Steel Thru-Hull Fittings
• Electrical System (220V/ 50 Cycle)
• Gel-Coated Dash Tan
• Gray Water System
• Head System (VacuFlush®) w/Direct Overboard Discharge - Int'l
• Macerator w/Seacock Interlock System
• Satellite Radio Hookup (12V) Sirius®
• Sport Spoiler Molded Fiberglass (Seamless) w/Overhead Lighting
• Spotlight, 5" Remote-Controlled
• Stereo Remote Control Additional Unit on Transom
• Storage Cradle
• Stove, 120V/60 Cycle Alcohol/Electric (Single-Burner)
• Table, Cockpit w/Designated Storage
• Windlass, Rope/Chain (Lofrans Marlin)
• Windlass, Rope/Chain w/Foot Switches (Lofrans Marlin)

Air Conditioning / Heating Options

• 7,000 BTU 120V/60 Cycle

Generator Options

• 5.0 kW Kohler® Gas 120V/60 Cycle - Includes Remote Start w/Muffler, Freshwater Cooling, Fuel Filter, Seacock & Seawater Strainer (Generator manufacturer and size may vary due to product availability.)

Electronics

• Depth Finder (Lowrance® 3500) Diesel Only
• VHF Radio (Raymarine 215) w/8' Fiberglass Antenna & Stainless Steel Ratchet Mount

Freight Options

• Inland Freight
• Minimum Late Change Charge
• Pre-rigged (North America Only)

Certifications

• Meets Applicable USCG & ABYC Standards
• NMMA Certification

Underwater Gear

• Propeller, Stainless Steel
• Trim Tabs, Hydraulic

V-berth

• Filler Cushions w/Dedicated Storage
• Hanging Locker
• Mirrored Rope Locker Bulkhead
• Seating, V-Berth w/Storage Below - Converts to Bed
• Storage, Gunwale Cabinets
• Table, Dinette w/Burl Wood Formica® Surface & Designated Storage

Water System

• Freshwater Washdown Spigot w/Dockside Water Inlet
• Pressure Water System w/12V Pump
• Water Heater (6-Gallon) 120V w/Exchanger
• Water Tank (28-Gallon)

Fuel System

• Fuel Lines, USCG Type A-1
• Fuel Tank w/Electric Shutoff Valve & Electric Sending Unit

Head

• Handrail, Stainless Steel
• Head (VacuFlush®)
• Head, Enclosed Full Fiberglass w/Shower & Curtain
• Mirror
• Vanity w/Sink, Faucet & Storage Below

Waste Systems

• Head System (VacuFlush®)
• Holding Tank (28-Gallon) w/Dockside Pump-Out
• Holding Tank Level Indicator Head
• Sump Box w/Pump - Automatic

Electrical Systems

• Battery Charger/Converter 120V/60 Cycle
• Battery Switch, Dual
• Battery Trays w/Mounts
• Fuse Block, Waterproof Electronic Interface Module w/Fuse Condition Monitor
• Isolator, Galvanic
• Panel, DC Main Breaker
• Panel, Main Distribution - AC
• Shore Power 30 Amp/120V/60 Cycle w/50' Cord & Adapter
• Wiring, Color-Coded w/Chafe Protection

Cabin Features

• Carbon Monoxide Monitor
• Carpet, Deep-Pile BCF 44-Ounce
• Lighting, 12V
• Outlets, 120V GFI Protected
• Stereo, 12V AM/FM Single CD Satellite-Ready w/Weatherproof Speakers (4) & Digital Cockpit Remote Control (Clarion®)
• Wood Interior Package Cherry Wood Formica® Cabinets

Canvas (sunbrella®)

• Aft Curtain w/Bungee Straps
• Bimini Top w/Boot & Vertical Storage
• Canvas Storage Bag
• Front Curtains
• Side Curtains

Control Station

• Alarms, Engine Oil & Water (Audible)
• Compass
• Horn
• Instrument Panels High-Gloss Burl
• Shift & Throttle Lever w/Trim Switch & Ignition Cutout Switch
• SmartCraft™ Diagnostics Instrumentation, Custom Sea Ray® SmartCraft w/Low-Glare Blue Night Lighting & Chrome Bezels (Includes: Tachometer, Speedometer, Fuel Level, Oil Pressure, Trim, Water Temperature) ; SmartCraft System Tachometer (Includes: Depth, Engine Alarms/Hourmeter, Fuel Consumption/Usage, Trim Level, Troll Control)
• Steering Wheel w/Black Spokes & Polished Centerpiece
• Steering, Power-Assisted
• Steering, Tilt Wheel
• Switch Pad Illuminated Waterproof Electronic w/ISO Symbols
• Tilt & Trim, Power (Stern Drives Only)

Galley

• Beverage Holders (2)
• Countertop, Molded Fiberglass w/Sink & Faucet
• Handrail Stainless Steel
• Lighting, 120V/12V Dual-Voltage
• Microwave, 120V
• Outlet, 12V Accessory
• Refrigerator, Dual-Voltage 120V/12V
• Storage, Upper & Lower
• Stove, Butane Single-Burner
• Trash Receptacle Under Step

Cockpit Features

• Beverage Holders (6)
• Cooler, Carry-On w/Designated Storage
• Door, Cabin Entry (Sliding & Lockable) - Fiberglass w/Integral Steps
• Door, Transom
• Floor Liner, Fiberglass Self-Bailing
• Hatch, Engine Room Gas-Assisted
• Lighting, Indirect
• Outlet, 120V GFI Protected
• Outlet, 12V Accessory
• Seating, Aft Bench (Foldaway)
• Seating, Aft-Facing w/Fold-Down Sun Pad - Port
• Seating, Bucket w/Swivel, Slider, Flip-Up Thigh-Rise Bolster & Rotocast Shell - Helm
• Seating, L-Shaped Lounger w/Forward & Aft-Facing Backrests - Port
• Steps, Boarding Molded-In
• Storage, Side Panels
• Wet Bar w/Sink, Faucet w/Pullout Sprayer, Beverage Holders, Stainless Steel Handrail & Storage Below

Engine Room

• Bilge Pump 12V Automatic
• Blower, 12V Bilge
• Fire Suppression System Automatic w/Manual Pull
• Gel-Coated Engine Room
• Insulated Engine Room
• Lighting, 12V
• Oil Filters - Remote

Hull & Deck Features

• Bow & Stern Eyes Stainless Steel
• Bow Rail Stainless Steel w/Welded Stanchions
• Cleats, (6) Thru-Bolted - Stainless Steel 8"
• Color Schemes (Blue, Green, Black/Tan)
• Deck Fill Plates Stainless Steel
• Drain Plug Brass-Threaded - Garboard
• Gel-Coat Arctic White
• Graphics, Striping
• Handrail - Lower Transom Stainless Steel w/Integral Ski Tow Eye
• Handrail - Upper Transom Stainless Steel
• Hatch, Deck Vent Translucent w/Locks & Sky Screen Cover (20x20)
• Light, Stern Removable
• Lights, Navigation Stainless Steel
• Portlights Stainless Steel (4 Opening)
• Resin High-Performance Vinylester
• Rub Rail, PVC w/Stainless Steel Insert
• Shrink Wrap
• Storage, Anchor w/Hatch
• Storage, Transom Wall for Fenders & Gear
• Swim Platform, Extended w/Concealed Stainless Steel Three-Step Swim Ladder & Integral Grab Handle
• Thru-Hull Fittings Color-Coordinated
• Vent System Engine Room - Integral
• Windshield Tempered/Tinted Curved Glass w/Walk-Thru & Stainless Steel Supports
• Windshield Wiper Starboard

Mid-stateroom

• Bunk, Double
• Curtain, Privacy
• Window, Sliding w/Screen
